Description

Rigid unbraked axle 1500kg PLUS axle type LS 1500

Replacement part identification number (ETI) 811660
Replacement part identification number watertight (ETI) 811733

Offset (ET) 27-33mm
B: Hole for centre pin only permitted at the top for strenght reasons!
D: Axle profile 60x5mm
E: Tightening torque of the bolt M12x80-10.9 DIN 931: 115 +- 5 Nm
F: Important: Position of weld on square tube at rear in driving direction! Mount axle stub with chamfer facing towards weld on square tube!
G: Driving direction

TECHNOLOGY
Model: PLUS
Axle type: LS 1500
Axle load: 1500kg
Wheel connection: 112×5 – M12x1.5

Comply with installation guidelines!

SCOPE OF DELIVERY
Axle
Wheel bolts loose

SURFACE TREATMENT
Axle profile hot-dip galvanised

ACCESSORIES
See following pages
